NVIDIA NVENC is a dedicated hardware encoder built into NVIDIA GPUs that enables high-performance video encoding without using CUDA cores or CPU resources. It is designed to handle real-time encoding for live streaming, batch compression, or low-latency video delivery.

Prerequisites

  • NVIDIA GPU with NVENC support
  • NVIDIA proprietary drivers installed
  • ffmpeg compiled with --enable-nvenc and linked with the NVIDIA Video Codec SDK
  • To verify NVENC support in FFmpeg, run:
code
ffmpeg -encoders | grep nvenc

This should list available NVENC encoders like h264_nvenc, hevc_nvenc.

Basic NVENC Commands

Once FFmpeg is configured with NVENC support, you can use NVENC for hardware-accelerated video encoding.

Banner

Encoding Video to H.264 (AVC) with NVENC:

Video is encoded to H.264 using NVIDIA"s hardware encoder and software AAC audio encoding.

code
ffmpeg -i input.mp4 -c:v h264_nvenc -c:a aac output.mp4

Explanation:

  • -c:v h264_nvenc: Tells FFmpeg to use NVENC to encode the video stream in H.264 format.
  • -c:a aac: Uses the AAC codec for audio encoding.

Encoding Video to H.265 (HEVC) with NVENC:

Encode video to the more efficient HEVC format using NVENC support on Maxwell GPUs and newer.

code
ffmpeg -i input.mp4 -c:v hevc_nvenc -c:a aac output.mp4

Explanation:

  • -c:v hevc_nvenc: Uses NVENC to encode the video stream in H.265 (HEVC) format.

Controlling Video Bitrate:

Shows how to set a fixed target bitrate using -b:v, which determines file size and compression level.

code
ffmpeg -i input.mp4 -c:v h264_nvenc -b:v 2M -c:a aac output.mp4

Explanation:

  • -b:v 2M: Sets the video bitrate to 2 Mbps.

Optimizing Encoding Speed and Quality

NVENC offers several options to balance encoding speed and video quality. These options are controlled through FFmpeg"s -preset and -tune parameters.

Encoding Speed and Quality Balance with Presets:

NVENC presets in FFmpeg are labeled numerically (p1 to p7), with p1 being fastest and p7 highest quality.

Example:

code
ffmpeg -i input.mp4 -c:v h264_nvenc -preset p7 -c:a aac output.mp4

Using Multiple GPUs with NVENC

FFmpeg can use all available GPUs for parallel processing for systems with multiple NVIDIA GPUs. The -hwaccel_device N option lets you specify which GPU to use for encoding.

Example of using multiple GPUs:

# GPU 0

code
ffmpeg -hwaccel_device 0 -i input.mp4 -c:v h264_nvenc output0.mp4

# GPU 1

code
ffmpeg -hwaccel_device 1 -i input.mp4 -c:v h264_nvenc output1.mp4

Explanation:

  • -hwaccel_device 0: Uses the first GPU for encoding.
  • -hwaccel_device 1: Uses the second GPU.

Advanced Features of NVENC

Rate Control Modes: NVENC supports multiple rate control modes to adjust how the encoder handles bitrate. Some of the key modes are:

CBR (Constant Bitrate): Maintains a constant bitrate for consistent video quality.

VBR (Variable Bitrate): Allows for efficient compression by varying the bitrate depending on the video complexity.

Example:

# CBR (Constant Bitrate)

code
ffmpeg -i input.mp4 -c:v h264_nvenc -rc cbr -b:v 5M -maxrate 5M -bufsize 5M -preset p4 -c:a aac output.mp4

# VBR (Variable Bitrate)

code
ffmpeg -i input.mp4 -c:v h264_nvenc -rc vbr -b:v 5M -maxrate 7M -bufsize 10M -preset p4 -c:a aac output.mp4

# Constant QP

code
ffmpeg -i input.mp4 -c:v h264_nvenc -rc constqp -qp 23 -preset p4 -c:a aac output.mp4

Explanation:

  • -rc: Rate control method (cbr, vbr, or constqp)
  • -qp: Quantizer value for CONSTQP (lower = better quality)

Motion Compensation and B-Frames:

NVENC can use motion compensation and B-frames for better compression. You can adjust these settings using the -b_ref_mode options.

Example: Setting the Number of B-frames

code
ffmpeg -i input.mp4 -c:v h264_nvenc -bf 4 -b_ref_mode each -c:a aac output.mp4

Explanation:

  • -bf 4: Enables up to 4 B-frames between P/I frames.
  • -b_ref_mode each: Allows B-frames to be used as reference frames for better efficiency.

Lookahead: Lookahead enables NVENC to analyze future frames and optimize rate allocation across them.

code
ffmpeg -i input.mp4 -c:v h264_nvenc -rc-lookahead 32 -c:a aac output.mp4

Explanation:

  • -rc-lookahead 32: Analyzes 32 future frames to improve compression.
  • Higher values increase latency but improve visual consistency.
